Do you know what fiber-reinforced polyethylene pipes are like?
Release Date:
2023-05-11
Author:
Dongrui Tianhe
Fiber-reinforced polyethylene piping is a novel material characterized by excellent flexibility, superior corrosion resistance, light weight, and outstanding impact resistance. It can be joined using hot‑melt butt fusion or electrofusion, seamlessly fusing pipes and fittings into a single unit. This results in a system that is safe, reliable, and cost‑effective, leading to its rapid adoption in engineering applications.

I. Hot-Melt Welding Technology for Fiber-Reinforced Polyethylene Pipes
Hot‑butt fusion is a method in which the pipe ends are heated and melted using a heating plate, then cooled to form a permanent joint. Typically, a hot‑fusion welding machine is used to heat the end sections until they melt, after which the pipes are quickly brought into contact, held under a specified pressure, and allowed to cool, thereby achieving a welded joint. Fiber‑reinforced polyethylene pipes of various sizes can be joined by hot‑butt fusion. However, for pipes with a nominal diameter less than 63 mm, socket‑type hot‑fusion joining is recommended. This method is economical and reliable, and when subjected to tensile or compressive loads, the joint exhibits higher strength than the pipe material itself.
II. Hot-Melt Welding Process
(1) Selection of Welding Method
All pipe joints shall be joined by electrofusion or hot‑fusion welding; mechanical connections are not permitted. The strength of a hot‑fusion joint exceeds that of the pipe itself, and since the connectors are made of plastic, corrosion is not an issue. The choice of connection method for fiber‑reinforced polyethylene pipes depends on the manufacturer’s requirements and recommendations, as well as the technical expertise of the on‑site installation personnel. Hot‑fusion joining involves first grinding, cleaning, and aligning the pipe ends, then heating them to their melting point to fuse the ends together. In industry, two hot‑fusion techniques are commonly used: butt fusion and socket fusion.
(2) Selection of Welding Equipment and Tools
The equipment utilizes 450 and 315 hot-melt butt welders, with hydraulic butt welders employed for assembly.
(3) Procedures and Requirements for Fiber-Reinforced Polyethylene Pipes Prior to Welding
Use a crowbar or support brackets to flatten the fiber-reinforced polyethylene pipe, adjust its concentricity, and employ clamps to correct any out-of-roundness, ensuring adequate welding clearance. Mill the pipe to an appropriate thickness so that the welded end faces are smooth and parallel, with a joint gap of less than 0.3 mm and an offset of no more than 10% of the wall thickness at the weld. When re‑clamping, re‑mill the clamping surfaces.
III. Key Points for Welding Operations
(1) Pipes shall be joined by hot‑fusion welding to pipe and fittings of the same grade and material. Connections between pipes of different brands but with similar material properties, or between fittings, shall be made only after testing has confirmed the quality of the joint.
(2) When the storage temperature differs significantly from the construction site temperature, allow the pipes and fittings to acclimatize on site for a sufficient period, enabling their temperature to approach that of the construction environment.
(3) When connecting fiber-reinforced polyethylene pipes, the cut surfaces must be clean. At the end of each workday, the pipe ends should be temporarily sealed.
(4) After connecting fiber-reinforced polyethylene pipes, inspect the appearance of the joints. Any joints that do not meet the requirements must be reworked, and following rework, the joint’s appearance shall be inspected again.
